Description
Engine
- Engine Brand: Kohler®
- Engine Model: Command V-Twin OHV
- Engine Displacement: 725cc
- Engine Output: 25 HP
- Fuel Tank Capacity: 3.3 gal. US (12.50 L)
- Cylinders/Material: 2/Cast-iron sleeve
- Engine Start: Electric
- Engine Oil Capacity: 1.9 qt. US (1.8 L)
- Lubrication: Fully-pressurized automotive-style oil pump w/spin-on oil filter
- Charging System: Flywheel Alternator – 15 amp regulated
- Choke: Separate Choke
Battery
- Battery: 12V / 300 cold crank amps
Drive System
- Transmission: Direct Shaft Drive, foot-controlled hydrostatic Hydro-Gear™ cast-iron transmission
- Transmission Housing: Cast iron
- Engine to Transmission: Heavy-duty belt
Cutting Deck
- Deck Cutting Width: Optional 42″, 50″, 54″ Stamped and 48″, 54, 60″ Fabricated
- Deck Wash: Patented SmartJet™ high-pressure deck washing system
- Deck Attach/Removal: QuickAttach™
- Deck Lift: Electric
- Cutting Height Range: 1.5″ – 4″
- Deck Positions: 6 Positions
Chassis
- Frame: Fully robotically-welded twin C-channel frame assembly
- Front Axle: Heavy-duty cast-iron with dual grease fittings
- Turning Radius: 18-in
- Front Tires: 16-in x 6.5-in
- Rear Tires: 23-in x 10.5-in
- Tire Tread: Turf Master™
- Protection: Brush Guard
Controls
- Cruise Control: Soft-touch engagement
- Direction: Electronic Power Steering (EPS)
- Brakes: Automotive-style disc
Comfort
- Seat Type: Deluxe high-back seat with armrests and 6″ slide
Additional Specifications
- Mulch Kit: Optional
- Headlight(s): LED High Illumination
- Cup holder included
- Model Number 14CD3LE-010
Warranty
- Warranty: 4-year unlimited hours (including powertrain)
- Frame Warranty: 5-year limited warranty
- Front Axle Warranty: 5-year limited warranty
- Deck Shell Warranty: Limited lifetime warranty on the fabricated deck shell
