Description
Engine
| Engine Model | 3HT-TM4B |
| Engine Gross Power | 44.9 hp (33.5 kW) |
| Rated Speed | 2,600 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Aspiration | Natural |
| Displacement | 111.4 cu.in. (1,826 cc) |
| Fuel Tank Capacity | 11.9 gal. (45 L) |
Transmission
| Transmission Type | Manual |
| Shuttle | Synchronized |
| Main Gear | |
| No. of Travel Speeds – Forward / Reverse | 8 x 8 |
| Min. Travel Speed of Forward w/ Ag @ Engine rated speed | 2.08 mph (3.35 km/h) |
| Max. Travel Speed of Forward w/ Ag @ Engine rated speed | 26.90 mph (43.20 km/h) |
Power Take-Off (PTO)
| PTO Type Trans | Independent |
| PTO Power | 41.6 hp (31 kW) |
| Rear PTO Speeds (1st) | 540 rpm |
Brakes and Clutch
| Brakes | Wet Multi Disc |
| Clutch | Dry Single Plate |
Dimensions w/ AG Tire
| Length w/ 3-point hitch | 124.3 in. (3,157 mm) |
| Width | 62.8 in. (1,596 mm) |
| Height from Top of ROPS Cab | 92 in. (2,338 mm) |
| Wheelbase | 71.3 in. (1,810 mm) |
| Ground Clearance | 14.5 in. (368 mm) |
| Front Tread Ag Tires – Min | 49.2 in. (1,251 mm) |
| Rear Tread Ag Tires – Min | 49.2 in. (1,251 mm) |
| Turning Radius w/ Brake | 8.6 ft. (2.6 m) |
Hydraulics
| Pump | Gear |
| Pump Capacity (Max. Flow Rate) | 14.5 GPM (55.1 L/min) |
3-Point Hitch
| Standard Category | Category I |
| Lift Capacity, 24″ aft of hitch | 2,716 lbs. (1,232 kg) |
| Control Type | Position |
Weight
| Weight with Ag Tires | 3,373 lbs. (1,530 kg) |
