DK5510

Big power without the big price tag.

Go ahead and compare the DK10 Series with the competition’s 45 to 55 HP models. When it comes to power, performance, and features for the money, these tractors are tough to beat.

  • Open Platform ROPS Design
  • Synchro Shuttle or H-Shuttle
  • Powerful & Rugged
  • Excellent Value

Learn More

Description

Engine

Engine Model 3HT-TM4B
Engine Gross Power 55 hp (41 kW)
Rated Speed 2,600 rpm
No. of Cylinders 3
Fuel Type Diesel
Aspiration Natural
Displacement 111.4 cu. in. (1,826 cc)
Fuel Tank Capacity 11.9 gal. (45 L)

Transmission

Transmission Type Synchro Shuttle
Shuttle Synchronized
Main Gear
No. of Travel Speeds – Forward / Reverse 8 x 8
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 2.08 mph (3.35 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 26.9 mph (43.3 km/h)

Power Take-Off (PTO)

PTO Type Trans Independent
PTO Power 49.6 hp (37 kW)
Rear PTO Speeds (1st) 540 rpm

Brakes and Clutch

Brakes Wet Multi Disc
Clutch Dry Single Plate

Dimensions w/ AG Tire

Length w/ 3-point hitch 124.8 in. (3,170 mm)
Width 62.8 in. (1,596 mm)
Height from Top of ROPS Cab 92 in. (2,338 mm)
Wheelbase 71.3 in. (1,810 mm)
Ground Clearance 15.2 in. (387 mm)
Front Tread Ag Tires – Min 49.2 in. (1,252 mm)
Rear Tread Ag Tires – Min 49.2 in. (1,252 mm)
Turning Radius w/ Brake 8.6 ft. (2.6 m)

Hydraulics

Pump Gear
Pump Capacity (Max. Flow Rate) 14.5 GPM (55.1 L/min)

3-Point Hitch

Standard Category Category II
Lift Capacity, 24″ aft of hitch 2,716 lbs. (1,232 kg)
Control Type Position

Weight

Weight with Ag Tires 3,373 lbs. (1,530 kg)
