DK5020

Main Features

  • Engine Gross Power: 50.3 hp (37.5 kW)
  • PTO Type: Independent
  • Transmission Type: Synchronized Shuttle
  • Shuttle: Dry Single Stage



  • Open Station (ROPS)
  • Rear differential lock
  • Push-button hydraulic independent PTO
  • Category I three-point hitch
  • PTO guard
  • NOTE: Front fenders not available in North America.

Learn More

Description

Engine

Engine Model 3HT-TM4B
Engine Gross Power 50.3 hp (37.5 kW)
Rated Speed 2,600 rpm
No. of Cylinders 3
Fuel Type Diesel
Aspiration Natural
Displacement 111.4 cu.in. (1,826 cc)
Fuel Tank Capacity 11.9 gal. (45 L)

Transmission

Transmission Type Synchro Shuttle
Shuttle Dry Type Single Stage
Main Gear
No. of Travel Speeds – Forward / Reverse 8 x 8
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 1.29 mph (2.08 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 16.71 mph (26.9 km/h)

Power Take-Off (PTO)

PTO Type Trans Independent
PTO Power 41.5 hp (31 kW)
Rear PTO Speeds (1st) 540 rpm

Brakes and Clutch

Brakes Wet Multi Disc
Clutch Dry Single Plate

Dimensions w/ AG Tire

Length w/ 3-point hitch 124.3 in. (3,157 mm)
Width 62.8 in. (1,596 mm)
Height from Top of ROPS Cab 96.8 in. (2,458 mm)
Wheelbase 71.3 in. (1,810 mm)
Ground Clearance 14.5 in. (368 mm)
Front Tread Ag Tires – Min 49.4 in. (1,255 mm)
Rear Tread Ag Tires – Min 49.3 in. (1,251 mm)
Turning Radius w/ Brake 102.8 in. (2,610 mm)

Hydraulics

Pump Gear
Pump Capacity (Max. Flow Rate) 14.56 gpm (55.1 L/min)

3-Point Hitch

Standard Category Category I
Lift Capacity, 24″ aft of hitch 2,716 lbs. (1,232 kg)
Control Type Position

Weight

Weight with Ag Tires 3,373 lbs. (1,530) kg

Equipment & Panel

Standard Equipment Optional Equipment Instrument Panel
  • Power Steering
  • Rear PTO
  • Wet Multi Disc Brakes
  • Drawbar
  • Headlights
  • Parking Brake
  • PTO Shield
  • Front Weights
  • Deck Mat
  • Clevis Type Drawbar
  • Side View Mirror (1 ea / ROPS Only)
  • Fuel Heater Kit
  • Single Remote Hydraulic Valve (Spring/Detent)
  • 2nd Remote Hydraulic Valve (Spring/Detent)
  • Rear Wheel Weight (Ag & Ind Tires Only)
  • 3rd Function Kit for Loader
  • Bluetooth Speaker Kit
  • RPM Increase Kit for Loader
  • Tachometer with Hour Meter
  • Fuel Gauge
  • Temperature Gauge
  • Oil Pressure Indicator
  • PTO Indicator
  • Low Fuel Indicator
  • Hydraulic Warning
  • Glow Plug Indicator
  • Low Coolant Indicator
  • Parking Brake Indicator

Available Tires

Agricultural

Front
Rear

Turf

Front
Rear

Industrial

Front
Rear

R14

Front
Rear



Attachments

Front End Loaders : KL5520

KL5520_450x230

Fits all DK20, DK10 and DK10SE Series ROPS Models. The KIOTI KL5520 front end loader is specifically designed for the DK10 & DK20 Series and ROPS models of the DK10SE Series. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. *Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Learn More about KL5520

Front End Loaders : KL5510

kl5510-3

Fits DK10 Series Models. (DK4510, DK4510HS, DK5010, DK5010HS, DK5510, DK5510HS) The KIOTI KL5510 front end loader is specifically designed for the DK10 Series tractors, providing efficient performance with single lever joystick control. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. *Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Learn More about KL5510

Backhoes : KB2485

KB2485-feature

Fits KIOTI DK10 Series (DK4510/5010/5510), NS Series (NS4710/NS4710 HST/NS5310 HST/NS6010/NS6010 HST), NX4510, NX5010, NX5510, NX6010, RX6620 tractors. Specifications may vary depending on tractor model and are subject to change without notification. Tractors must be equipped with ROPS and seat belt that will provide greater safety.
