DK5320SE HST

Main Features

  • Engine Gross Power: 50.3 lbs (37.5 kW)
  • PTO Type: Independent
  • Transmission Type: HST
  • Shuttle: N/A
  • KIOTI Diesel Engine
  • Open Platform ROPS Design
  • Powerful HST Transmission
  • Dual HST Pedals
  • NOTE: Front fenders not available in North America.

Learn More

Description

Engine

Engine Model 3H-TH4C
Engine Gross Power 50.3 hp (37.5 kW)
Rated Speed 2,600 rpm
No. of Cylinders 3
Fuel Type Diesel
Displacement 111.4 cu. in. (1,826 cc)
Fuel Tank Capacity 12.7 gal. (48 L)

Transmission

Transmission Type Hydrostatic
No. of Travel Speeds – Forward / Reverse 3 Range
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 18.5 mph (29.7 km/h)

Power Take-Off (PTO)

PTO Type Transmission Independent
PTO Power 39.3 hp (29.3 kW)
Rear PTO Speed 540 rpm
Mid PTO Speed 2,000 rpm (Optional)

Brakes and Clutch

Brakes Wet Disc Type
Clutch None

Dimensions w/ AG Tire

Length w/ 3-point hitch 125.5 in. (3,189 mm)
Width 62.8 in. (1,596 mm)
Height from Top of ROPs 96.8 in. (2,458 mm)
Wheelbase 71.3 in. (1,810 mm)
Ground Clearance 14.5 in. (368 mm)
Front Tread Ag Tires – Min 49.4 in. (1,254 mm)
Rear Tread Ag Tires – Min 49.03 in. (1,251 mm)
Min. Turning Radius w/ Brake 102.8 in. (2,610 mm)

Hydraulics

Total Pump Flow 16.4 gpm (62.4 L/min)

3-Point Hitch

Standard Category Category 1
Lift Capacity, 24″ aft of hitch 2,716 lbs. (1,232 kg)
Control Type Position

Weight

Weight w/ Ag Tires w/ ROPs 3,523 lbs. (1,598 kg)



Equipment & Panel

Standard Equipment Optional Equipment Instrument Panel
  • Power Steering
  • Rear PTO
  • Dual Remote Hydraulic Valve (Spring/Detent)
  • Wet Multi Disc Brakes
  • Joystick Valve
  • Drawbar
  • Headlights
  • Parking Brake
  • PTO Shield
  • Beacon Light
  • Front Weights
  • Mid PTO
  • HST Linked Pedal
  • Fuel Heater Kit
  • Rear Wheel Weight (Ag and Ind Tires Only)
  • 3rd Function Kit for Loader
  • RPM Increase Kit for Loader
  • Bluetooth Speaker Kit
  • Clevis Type Drawbar
  • Side View Mirror
  • Digital Hour Meter
  • Coolant Temperature Gauge
  • Tachometer
  • Fuel Gauge
  • Engine Oil Pressure Light
  • High Beam, Emergency Flasher, Turn Signals
  • Glow Plug Light
  • Alternator Light

Available Tires

Agriculture

Front
Rear

Turf

Front
Rear

Industrial

Front
Rear

R14

Front
Rear



Attachments

Front End Loaders : KL5520

KL5520_450x230

Fits all DK20, DK10 and DK10SE Series ROPS Models. The KIOTI KL5520 front end loader is specifically designed for the DK10 & DK20 Series and ROPS models of the DK10SE Series. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. *Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Learn More about KL5520

Backhoes : KB2485

KB2485-feature

Fits KIOTI DK10 Series (DK4510/5010/5510), NS Series (NS4710/NS4710 HST/NS5310 HST/NS6010/NS6010 HST), NX4510, NX5010, NX5510, NX6010, RX6620 tractors. Specifications may vary depending on tractor model and are subject to change without notification. Tractors must be equipped with ROPS and seat belt that will provide greater safety.
