Description
Engine
Engine Model | 3C100LFU-U2 |
Engine Type | 4-Cycle Diesel, 3 Cyl., Inline Vertical, Water-Cooled |
Engine Gross | 24 hp (17.89 kW) |
Displacement | 61.45 cu. in. (1,007 cc) |
Rated Revolution | 3,000 rpm |
Fuel Tank Capacity | 9.7 gal. (37 ℓ) |
Drive Train
Type | Belt CVT |
Gear Range | Low, High, Neutral, Reverse |
Ground Speed | 0-31 mph (0-50 km/h) |
Brake | Front/Rear Hydraulic Disc |
Suspension
Front Suspension | Independent, Double A-Arm (Wishbone Type) |
Rear Suspension | Independent, Double A-Arm (Wishbone Type) |
Steering
Type | Hydraulic Power |
Dimensions
Length | 119.8 in. (3,045 mm) |
Width | 62.5 in. (1,590 mm) |
Height | 76.7 in. (1,950 mm) |
Max Front Wheel Tread | 49.7 in. (1,262 mm) |
Max Rear Wheel Tread | 49.8 in. (1,264 mm) |
Wheelbase | 85.8 in. (2,180 mm) |
Weight | 2,050 lbs. (930 kg) |
Ground Clearance | 12.5 in. (318 mm) |
Towing Capacity | 1,300 lbs. (590 kg) |
Payload Capacity | 1,598 lbs. (725 kg) |
Turning Radius | 14.1 ft. (4.3 m) |
Cargo Bed
Length x Width x Depth | 43.7 x 58.2 x 11.5 in. (1,110 x 1,480 x 293 mm) |
Bed Capacity | 1,102 lbs. (500 kg) |
