Description
Specifications
Model | PW180 |
Shipping Weight (LBS.) | 4,400 |
3PH Mount | Draw Bar Hitch |
Cutting Height | 3″-15″ |
Cutting Path | 180″ |
Max Brush Diameter | 1.5″ |
Overall Width (Wings Down) | 184″ |
Folded Width (Wings Up) | 78″ |
Tip Speed (Ft/Min) | 15,100 ft/min on Wings 14,850 ft/min on center |
Wheels (Pneumatic) | 21″ |
Blades | 9 blades 1/2″x4″ |
Tractor HP (min) | 75HP |
PTO RPM | 540 |
Gearbox Rating (Wing) | 140 HP |
Gearbox Rating (Center) | 105 HP |
Gearbox Rating (Divider) | 87 HP |
Deck | 3/16″ |
Stump Jumper | Yes |
Protection | Independent Slip Clutch on Each Spindle |

Pneumatic Wheels

20° Contour Cutting

Gearbox

Standard Chain Curtain

3 Blade Assembly

Steel Blade Guard
