Description
Specifications
| Model | UTVM48 | UTVM48E |
| Engine Brand | Briggs & Stratton | Briggs & Stratton |
| Engine HP | 19 | 2 Engines (190 CC each) |
| Starting System | Key (electric) | Pull Start |
| Fuel Tank | 3 Gal. | 1 Gal. |
| Battery | 12 Volt | N/A |
| Deck | Rear Discharge | Rear Discharge |
| Deck Thickness | 10 ga | 10 ga |
| Blade Assembly | 2 Rotors with 3 Blades each | 2 Rotors with 3 Blades each |
| Cut Width | 44″ | 48″ |
| Cut Height | 2″ – 7″ | 2″ – 6″ |
| Max Brush Diameter | 3/4″ | 1/2″ |
| Wheels | 14 x 6 | 2 1/2″ X 12″ |
| Weight | 720 lbs | 325 lbs |
Engine
Features a 19HP Professional Series Briggs & Stratton Engine with electric start.
12V Battery
The mower has an onboard 12 Volt system. With its own isolated system it can be run on almost any utility vehicle.
Remote e-Stop
Cabled e-Stop can be placed on tow vehicle for easy reach.
Control Panel
All the controls required to run the mower are conveniently on the left of the cutter.
Blades
The cutting platform utilizes 2 rotors consisting of 3 blades each.
Cutting Height
A ratchet-style adjuster provides easy adjustment of the cutting height between 2″-7″.
Adjustable Towing
The tow bar can be positioned for left or right offset as well as straight behind the tow vehicle.
Attaching the mower to your drawbar with a clevis allows it to better follow the terrain.
Wheels
The trail mower uses flat-free tires. The front two wheels swivel for optimal movement and the rear two are fixed in position.
