Description
Specifications
Model | M-910 |
HP Requirements | 45-75hp |
Min. Tractor Weight | 3,000 lbs. |
Bale Size36″x40 | 250-300lbs. |
Baler Dimensions – Length |
118″ |
Width | 87″ |
Height | 65″ |
Pickup Width | 37 1/2″ |
Weight (lbs.) | 3740 |
Working Speed | 2-5 km/hr – 80-120 bales/hour |
HItch Type | Cat. 1 or Cat.2, 3 pt. hitch |
Tire Size | 10×8.0-12 |
PTO | 540RPM Shear bolt protected driveline |
Hydraulics | Single rear hyd. remote req. |
Bale Binding Type | Twine – Auto wrap |
Bale Chamber Indicator | Electric Horn |
Bale Compression Type | 19 Steel Rollers – No belts! |
Bale Density Settings | 3 (manual) |
Pickup Adjustment | Chain |
Lift Gate | Hydraulic lift gate – Push button |
