Description
| Production | |
| Manufacturer: | John Deere |
| Type: | Compact Utility tractor |
| Factory: | Augusta, Georgia, USA |
| John Deere 2025R Power | |
| Engine (gross): | 24.2 hp 18.0 kW |
| Engine: | 25 hp 18.6 kW |
| PTO (claimed): | 18 hp 13.4 kW |
| John Deere 2025R Engine | |
| Yanmar 1.3L 3-cyl diesel | |
 Â Engine details … |
| Mechanical | |
| Chassis: | 4×4 MFWD 4WD |
| Final drives: | spur gear |
| Differential lock: | standard |
| Steering: | power |
| Brakes: | wet disc |
| Cab: | Two-post foldable ROPS. |
| Transmission: | hydrostatic |
 Â Transmission details … |
|
| Photos | |
 Â John Deere 2025R photos… |
|
| Capacity | |
| Fuel: | 6.1 gal 23.1 L |
| Hydraulic system: | 2.6 gal 9.8 L |
| Front axle: | 0.9 qts 0.9 L |
| Hydraulics | |
| Type: | open center |
| Capacity: | 2.6 gal 9.8 L |
| Pressure: | 2421 psi 166.9 bar |
| Pump flow: | 3.4 gpm 12.9 lpm |
| Total flow: | 5.6 gpm 21.2 lpm |
| Steering flow: | 2.2 gpm 8.3 lpm |
| Tractor hitch | |
| Rear Type: | I |
| Control: | position control |
| Rear lift (at ends): | 1433 lbs 650 kg |
| Rear lift (at 24″/610mm): | 1150 lbs 521 kg |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | wet disc |
| Rear RPM: | 540 |
| Mid PTO: | independent |
| Mid RPM: | 2000 |
| Dimensions & Tires | |
| Wheelbase: | 63 inches 160 cm |
| Weight: | 1660 lbs 752 kg |
 Â Full dimensions and tires … |
|
| John Deere 2025R attachments | |
| 54″ mid-mount mower deck | |
| 62″ mid-mount mower deck | |
| snowblower | |
| blade | |
| front-end loader | |
| backhoe | |
 Â Attachment details … |
| 2025R Serial Numbers | |
| Location: | Right side of tractor frame, above and behind the front axle. |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 20 |
| Charging volts: | 12 |
| Battery CCA: | 500 |
| Battery volts: | 12 |
