Description
| Lift Capacity: | 4500 lbs (2041 kg) |
|---|---|
| Engine HP Range: | 55 – 120 |
| Required Hydraulic Flow: | 5 gpm (19 lpm) |
| Grapple Opening: | 3″ – 72″ (8 cm – 182 cm) |
| Grapple Rotation: | 180° |
| Clamp Force: | 21000 lbs (9525 kg) |
| Push Bar Width: | 19″ (48 cm) |
| Rotator/Pivot Rating: | 9000 lbs (4082 kg) |
| Total Weight: | 836 lbs (380 kg) |
| Dimensions (LxWxH): | 70″ x 76″ x 56″ (178 cm x 193 cm x 143 cm) |
| Mounting System: | Cat II & III |
