Description
| Chipping Capacity: | 5″ (13 cm) |
|---|---|
| Chipper Type: | Disc |
| Feed System: | Dual Hydraulic Roller Feed |
| Engine HP Range: | 30 – 55 |
| Required Hydraulic Flow: | 3 – 6 gpm (12 – 23 lpm) |
| Chipper Hopper Opening: | 35″ x 30″ (89 cm x 76 cm) |
| Chipper Housing Opening: | 5″ x 10″ (13 cm x 26 cm) |
| Number Of Chipper Knives: | 4 |
| Rotor Diameter: | 25″ (63 cm) |
| Rotor Weight : | 125 lbs (57 kg) |
| Discharge Chute Height: | 74″ (188 cm) |
| Discharge Chute Rotation: | 360° |
| Drive System: | PTO Direct Drive |
| Rated RPM: | 540 – 1000 |
| PTO Height: | 22″ – 27″ (55 cm – 69 cm) |
| Total Weight: | 845 lbs (384 kg) |
| Dimensions Open (LxWxH): | 80″ x 67″ x 74″ (204 cm x 171 cm x 188 cm) |
| Dimensions Folded (LxWxH): | 62″ x 61″ x 74″ (158 cm x 155 cm x 188 cm) |
| Mounting System: | Cat I, iMatch™ & Quick Hitch Compatible |
