CK2620 HST

Main Features

  • Engine Gross Power: 24.5 HP (18.2 kW)
  • PTO Type: Live
  • Transmission Type: Hydrostatic
  • Shuttle: Dry Single Stage
  • KIOTI Diesel Engine
  • Hydrostatic Power Steering
  • Hydrostatic Transmission
  • Rear PTO
  • Single Lever Joystick Standard
  • Available with Field Option Cab
  • NOTE: Front fenders not available in North America.

Learn More

Description

Engine

Engine Model 3A165LWM-U
Engine Gross Power 24.5 hp (18.2 kW)
Rated Speed 2,400 rpm
No. of Cylinders 3
Fuel Type Diesel
Aspiration Natural
Displacement 100.5 cu. in. (1,647 cc)
Fuel Tank Capacity 9 gal. (34 L)

Transmission

Transmission Type Hydrostatic
No. of Travel Speeds – Forward / Reverse Infinite, 3 Range
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0.75 mph (1.21 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 9.79 mph (15.75 km/h)

Power Take-Off (PTO)

PTO Type Trans Live
PTO Power 21.5 hp (16 kW)
Rear PTO Speeds (1st) 540 rpm
Mid PTO Speeds 2,000 rpm (Optional)

Brakes and Clutch

Brakes Wet Multi Disc
Clutch Dry Single Stage

Dimensions w/ AG Tire

Length w/ 3-point hitch 120.9 in. (3,070 mm)
Width 54.5 in. (1,385 mm)
Height from Top of ROPS 92.91 in. (2,260 mm)
Wheelbase 65.7 in. (1,670 mm)
Ground Clearance 13.39 in. (340 mm)
Front Tread Ag Tires – Min 48.2 in (1,225 mm)
Rear Tread Ag Tires – Min 47.6 in. (1,210 mm)
Min. Turning Radius w/ Brake 107 in. (2,730 mm)

Hydraulics

Total Pump Flow 11.73 gpm (44.4 L/min)

3-Point Hitch

Standard Category Category 1
Lift Capacity, 24″ aft of hitch 1,631 lbs. (740 kg)
Control Type Position

Weight

Weight w/ Ag Tires w/ ROPS 2,635 lbs. (1,195 kg)

Equipment & Panel

Standard Equipment Optional Equipment Instrument Panel
  • Power Steering
  • Rear PTO
  • Wet Multi Disc Brakes
  • Joystick Valve
  • Drawbar
  • Headlights
  • Parking Brake
  • PTO Shield
  • Front Weights
  • Mid PTO
  • HST Linked Pedal (HST Only)
  • Clevis Type Drawbar
  • Side View Mirror (1 ea)
  • Dual Remote Hydraulic Valve (Non-Detent)
  • Dual Remote Hydraulic Valve (Spring/Detent/Dual Detent)
  • Fuel Heater Kit (N/A on CK2620)
  • Rear Wheel Weight (Ag Tire Only)
  • 3rd Function Kit for Front End Loader
  • Digital Hour Meter
  • Coolant Temperature Gauge
  • Electrical Tachometer
  • Fuel Gauge
  • Engine Oil Pressure Light
  • High Beam, Emergency Flasher, Direction Indicators
  • Glow Plug Light
  • Alternator Light

Available Tires

Agriculture

Front
Rear

Turf

Front
Rear

Industrial

Front
Rear

R14

Front
Rear

Attachments

Front End Loaders : KL4030

KL4030_LOADER_w_Pallet_Forks

Fits the CK20, CK20SE, CK10 and CK10SE Series models.  The KIOTI KL4030 front end loader is specifically designed for the model tractors in the CK20, CK20SE, CK10 and CK10SE Series, providing efficient performance with single lever joystick control. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. The KL4030 and KL4030C are both compatible with the KIOTI CK10 and CK10SE Series. For product availability in your region, please see your authorized KIOTI dealer for details.*Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Learn More about KL4030

Backhoes : KB2475L

KB24751

Fits the KIOTI CK2610, CK2610 HST, CK3510, CK3510 HST, CK4010, CK4010 HST. *Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Learn More about KB2475L

Front End Loaders : KL2610

KL2610_LOADER_w_Pallet_Forks

Fits the KIOTI CK2610 & CK2610 HST models. Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Implements

Products: Implements

Implements_FEATURE_IMAGE

Mowing, cutting, tilling, haying, hauling. Whatever the job is, KIOTI has user-friendly, high-performance implements to help you get it done.
