Description
Engine
| Engine Model | 3H-TH4A |
| Engine Gross Power | 39.6 hp (29.5 kW) |
| Rated Speed | 2,600 rpm |
| No. of Cylinders | 3 |
| Fuel Type | Diesel |
| Aspiration | Natural |
| Displacement | 111.4 cu. in. (1,826 cc) |
| Fuel Tank Capacity | 9.0 gal. (34 L) |
Transmission
| Transmission Type | HST |
| Main Gear | Manual |
| No. of Travel Speeds – Forward / Reverse | Infinite, 3 Range |
| Min. Travel Speed of Forward w/ Ag @ Engine rated speed | 0 mph (0 km/h) |
| Max. Travel Speed of Forward w/ Ag @ Engine rated speed | 14.85 mph (23.91 km/h) |
Power Take-Off (PTO)
| PTO Type Trans | Live |
| PTO Power | 33.3 hp (24.8 kW) |
| Rear PTO Speeds (1st) | 540 rpm |
| Mid PTO Speeds | 2,000 rpm (Optional) |
Brakes and Clutch
| Brakes | Wet Multi Disc |
| Clutch | Dry Single Stage |
Dimensions w/ AG Tire
| Length w/ 3-point hitch | 120.9 in. (3,070 mm) |
| Width | 54.5 in. (1,385 mm) |
| Height from Top of ROPS | 92.91 in. (2,520 mm) |
| Wheelbase | 65.7 in. (1,670 mm) |
| Ground Clearance | 13.4 in. (340 mm) |
| Front Tread Ag Tires – Min | 48.2 in (1,225 mm) |
| Rear Tread Ag Tires – Min | 47.6 in. (1,210 mm) |
| Min. Turning Radius w/ Brake | 107.48 in. (2,730 mm) |
Hydraulics
| Total Pump Flow | 11.7 gpm (44.4 L/min) |
3-Point Hitch
| Standard Category | Category 1 |
| Lift Capacity, 24″ aft of hitch | 1,631 lbs. (740 kg) |
| Control Type | Position |
Weight
| Weight w/ Ag Tires w/ ROPS | 2,734 lbs. (1,240 kg) |
Equipment & Panel
| Standard Equipment | Optional Equipment | Instrument Panel |
|---|---|---|
|
|
|
Available Tires
 |
Agriculture |
Front Rear |
 |
Turf |
Front Rear |
 |
Industrial |
Front Rear |
 |
R14 |
Front Rear |
Attachments
Front End Loaders : KL4030
Fits the CK20, CK20SE, CK10 and CK10SE Series models. The KIOTI KL4030 front end loader is specifically designed for the model tractors in the CK20, CK20SE, CK10 and CK10SE Series, providing efficient performance with single lever joystick control. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. The KL4030 and KL4030C are both compatible with the KIOTI CK10 and CK10SE Series. For product availability in your region, please see your authorized KIOTI dealer for details.*Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification. |
Backhoes : KB2475L
Fits the KIOTI CK2610, CK2610 HST, CK3510, CK3510 HST, CK4010, CK4010 HST. *Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification. |
Front End Loaders : KL4010
Fits the CK10 Series Models. (CK3510/CK3510H/CK4010/CK4010H) The KIOTI KL4010 front end loader is specifically designed for the CK10 Series tractors, providing efficient performance with single lever joystick control. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. *Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification. |
Implements
Products : Implements
Mowing, cutting, tilling, haying, hauling. Whatever the job is, KIOTI has user-friendly, high performance implements to help you get it done. |
