CK2620SE HST

Main Features

  • Engine Gross Power: 24.5 hp (18.2 kW)
  • PTO Type: Independent
  • Transmission Type: HST
  • Shuttle: N/A
  • KIOTI Diesel Engine
  • Power Steering
  • Single Lever Joystick
  • 3-Point Control Lever
  • NOTE: Front fenders not available in North America.

Learn More

Book a Test Drive
Category:

Description

Engine

Engine Model 3H-TM4B
Engine Gross Power 24.5 hp (18.2 kW)
Rated Speed 2,400 rpm
No. of Cylinders 3
Fuel Type Diesel
Displacement 100.5 cu. in. (1,647 cc)
Fuel Tank Capacity 9 gal. (34 L)

Transmission

Transmission Type Hydrostatic
No. of Travel Speeds – Forward / Reverse 3 range
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0 mph (0 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 10.01 mph (16.11 km/h)

Power Take-Off (PTO)

PTO Type Transmission Independent
PTO Power 18.7 hp (13.9 kW)
Rear PTO Speed 540 rpm
Mid PTO Speed 2,000 rpm (Optional)

Brakes and Clutch

Brakes Wet Disc Type
Clutch N/A

Dimensions w/ AG Tire

Length w/ 3-point hitch 120.87 in. (3,070 mm)
Width 54.53 in. (1,385 mm)
Height from Top of ROPs
Wheelbase 65.75 in. (1,670 mm)
Ground Clearance 13.39 in. (340 mm)
Front Tread Ag Tires – Min 48.22 in (1,225 mm)
Rear Tread Ag Tires – Min 47.04 in. (1,210 mm)
Min. Turning Radius w/ Brake 107.48 in. (2,730 mm)

Hydraulics

Total Pump Flow 11.3 gpm (42.9 L/min)

3-Point Hitch

Standard Category Category 1
Lift Capacity, 24″ aft of hitch 1,631 lbs. (740 kg)
Control Type Position

Weight

Weight w/ Ag Tires w/ ROPs 3,397 lbs. (1,541 kg)

Equipment & Panel

Standard Equipment Optional Equipment Instrument Panel
  • Power Steering
  • Rear PTO
  • Dual Remote Hydraulic Valve (Spring/Detent)
  • Wet Multi Disc Brakes
  • Joystick Valve
  • Drawbar
  • Front Working Lights (Cab)
  • Rear Working Light (Cab)
  • Headlights
  • Parking Brake
  • PTO Shield
  • Beacon Light
  • Front Weights
  • Mid PTO
  • HST Linked Pedal (HST Only)
  • Rear Wheel Weight (Ag Tire Only)
  • 3rd Function Kit for Loader
  • Clevis Type Drawbar
  • Digital Hour Meter
  • Coolant Temperature Gauge
  • Tachometer
  • Fuel Gauge
  • Engine Oil Pressure Light
  • High Beam, Emergency Flasher, Turn Signals
  • Glow Plug Light
  • Alternator Light

Available Tires

Agriculture

 Front
Rear

Turf

 Front
Rear

Industrial

 Front
Rear

R14

 Front
Rear



Attachments

Front End Loaders: KL4030

KL4030_LOADER_w_Pallet_Forks

Fits the CK20, CK20SE, CK10 and CK10SE Series models.  The KIOTI KL4030 front end loader is specifically designed for the model tractors in the CK20, CK20SE, CK10 and CK10SE Series, providing efficient performance with single lever joystick control. The KIOTI loader, with a built-in parking stand, is designed to be quickly and easily attached and detached. KL Series loaders utilize the tractor’s hydraulic system, feature single-lever control with float and come with a bucket level indicator. The KL4030 and KL4030C are both compatible with the KIOTI CK10 and CK10SE Series. For product availability in your region, please see your authorized KIOTI dealer for details.*Specifications may vary with tractor model, front axle configurations, tire size option and type of attachment and are subject to change without notification.

Learn More about KL4030

Backhoes : KB2475L

KB24751

Fits the KIOTI CK2610, CK2610 HST, CK3510, CK3510 HST, CK4010, CK4010 HST. *Specifications may vary with tractor model, front axle configurations, tire size option, and type of attachment and are subject to change without notification.



Products: Implements

Implements_FEATURE_IMAGE

Mowing, cutting, tilling, haying, hauling. Whatever the job is, KIOTI has user-friendly, high-performance implements to help you get it done.
