NX4510

EVERYTHING YOU NEED TO MAKE HARD WORK SEEM EASY.

Powerful? Check. Fuel-efficient? Check. All around awesome? Check. If you’re looking for a 45 to 60 hp workhorse that’ll get it done in style, we present you with the NX Series.

  • Cab & ROPS Models
  • Synchro Shuttle or HST
  • Loaded with Features
  • Daedong® ECO Engine Technology
  • Hydraulic Independent PTO
  • Cruise Control (HST Models)

Learn More

Description

Engine

Engine Model 3F183T
Engine Gross Power 45 hp (33.6 kW)
Rated Speed 2,600 rpm
No. of Cylinders 3
Fuel Type Diesel
Aspiration Turbo Charged
Displacement 111.4 cu. in. (1,826 cc)
Fuel Tank Capacity 14.8 gal. (56 L)

Transmission

Transmission Type Manual
Shuttle Synchronized
Main Gear Synchronized
No. of Travel Speeds – Forward / Reverse 24 x 24
Min. Travel Speed of Forward w/ Ag @ Engine rated speed 0.11 mph (0.17 km/h)
Max. Travel Speed of Forward w/ Ag @ Engine rated speed 15.71 mph (25.28 km/h)

Power Take-Off (PTO)

PTO Type Trans Independent
PTO Power 37.6 hp (28 kW)
Rear PTO Speeds (1st) 540 rpm
Mid PTO Speeds 2,000 rpm (Optional)

Brakes and Clutch

Brakes Wet Multi Disc
Clutch Dry Single Plate

Dimensions w/ AG Tire

Length w/ 3-point hitch 139.6 in. (3,547 mm)
Width 65.6 in. (1,665 mm)
Height from Top of ROPS Cab 103.1 in. (2,618 mm)
Wheelbase 75.6 in. (1,920 mm)
Ground Clearance 13.7 in. (350 mm)
Front Tread Ag Tires – Min 55.2 in. (1,352 mm)
Rear Tread Ag Tires – Min 52.1 in. (1,324 mm)
Turning Radius w/ Brake 9.81 ft. (2.99 m)

Hydraulics

Pump Gear
Pump Capacity (Max. Flow Rate) 16.5 GPM (62.4 L/min)

3-Point Hitch

Standard Category Category I
Lift Capacity, 24″ aft of hitch 3,177 lbs. (1,441 kg)
Control Type Position with Draft Control

Weight

Weight with Ag Tires 3,978 lbs. (1,804.4 kg)
