KIOTI K9 2400 UTV

K9 2440

The new KIOTI K9 2440 UTV.  A Landowners Best Friend. Fully-Featured, Tough, and Reliable Companion. The K9 2440 offers contemporary styling, an abundance of storage and two rows of seating. With a 24 horsepower, 3 cylinders, inline vertical, water-cooled Daedong diesel engine with a ground speed up to 31 mph, landowners will rejoice. *Payload capacity includes passengers.

Main Features

  • Engine Gross Power: 24 hp (17.89 kW)
  • PTO Type: N/A
  • Transmission Type: Belt Driven CVT
  • Shuttle: N/A

Learn More

Book a Test Drive
Category:

Description

Engine

Engine Model 3C100LFU-U2
Engine Type 4-Cycle Diesel, 3 Cyl., Inline Vertical, Water-Cooled
Engine Gross 24 hp (17.89 kW)
Displacement 61.45 cu. in. (1,007 cc)
Rated Revolution 3,000 rpm
Fuel Tank Capacity 9.7 gal. (37 ℓ)

Drive Train

Type Belt CVT
Gear Range Low, High, Neutral, Reverse
Ground Speed 0-31 mph (0-50 km/h)
Brake Front/Rear Hydraulic Disc

Suspension

Front Suspension Independent, Double A-Arm (Wishbone Type)
Rear Suspension Independent, Double A-Arm (Wishbone Type)

Steering

Type Hydraulic Power

Dimensions

Length 149.2 in. (3,790 mm)
Width 62.5 in. (1,590 mm)
Height 76.9 in. (1,955 mm)
Wheelbase 112.2 in. (2,850 mm)
Ground Clearance 12 in. (304 mm)
Max Front Wheel Tread 49.7 in. (1,262 mm)
Max Rear Wheel Tread 49.8 in. (1,264 mm)
Turning Radius 18.4 ft. (5.6 m)
Weight 2,314.8 lbs. (1,050 kg)
Towing Capacity 1,300 lbs. (590 kg)
Payload Capacity 1,750.5 lbs. (725 kg)

Cargo Bed

Length x Width x Depth 39.2 x 58.2 x 11.5 in. (1,010 x 1,480 x 293 mm)
Bed Capacity 661.5 lbs. (300 kg)
