Description
| Chipping Capacity: | 10″ (25 cm) |
|---|---|
| Chipper Type: | Disc |
| Feed System: | Dual Hydraulic Roller Feed |
| Engine HP Range: | 80 – 120 |
| Required Hydraulic Flow: | 4 – 8 gpm (15 – 30 lpm) |
| Chipper Hopper Opening: | 30″ x 42″ (76 cm x 107 cm) |
| Chipper Housing Opening: | 10″ x 17″ (25 cm x 43 cm) |
| Number Of Chipper Knives: | 4 |
| Rotor Diameter: | 36” (92 cm) |
| Rotor Weight : | 425 lbs (193 kg) |
| Discharge Chute Height: | 100″ (253 cm) |
| Discharge Chute Rotation: | 360° |
| Winch Pulling Capacity: | 1200 lbs (545 kg) |
| Winch Rope Length: | 50′ (15 m) |
| Winch Rope Diameter: | 1/4″ (6 mm) |
| Drive System: | PTO Direct Drive |
| Rated RPM: | 540 – 1000 |
| PTO Height: | 34″ (86 cm) |
| Total Weight: | 2100 lbs (953 kg) |
| Dimensions Open (LxWxH): | 108″ x 85″ x 100″ (273 cm x 215 cm x 253 cm) |
| Dimensions Folded (LxWxH): | 85″ x 71″ x 100″ (215 cm x 180 cm x 253 cm) |
| Mounting System: | Cat II, iMatch™ & Quick Hitch Compatible |
