Powered from your mini-skid steer, the WX200 series are quick to split. With powerful splitting force and the ease of connecting to your skid steer, your job will be finished in no time.

Learn More


Split Force: 20 Ton
Recommended Minimum HP: 23
Recommended Hydraulic Flow: 10 gpm (38 lpm)
Split Opening: 24″ (61 cm)
Orientation: Inverted Horizontal
Average Splitter Cycle Time: 6.62 Seconds *depends on flow from mini skid steer
Full Cycle: 13.24 Seconds *depends on flow from mini skid steer
Cylinder Diameter: 4″ (10 cm)
Wedge Height: 9″ (23 cm)
Total Weight: 334 lbs (152 kg)
Dimensions (LxWxH): 73″ x 24″ x 19.5″ (185 cm x 61 cm x 50 cm)
Mounting System: Mini Skidsteer Mounting Plate (Excludes Bobcat)
