BX102R

With a PTO powered rotor and hydraulic feed hopper, branches, limbs and brush up to 10″ in diameter are control fed for continuous chipping at maximum capacity.

Learn More

Description

Chipping Capacity: 10″ (25 cm)
Chipper Type: Disc
Feed System: Dual Hydraulic Roller Feed
Engine HP Range: 80 – 120
Required Hydraulic Flow: 4 – 8 gpm (15 – 30 lpm)
Chipper Hopper Opening: 30″ x 42″ (76 cm x 107 cm)
Chipper Housing Opening: 10″ x 17″ (25 cm x 43 cm)
Number Of Chipper Knives: 4
Rotor Diameter: 36” (92 cm)
Rotor Weight : 425 lbs (193 kg)
Discharge Chute Height: 100″ (253 cm)
Discharge Chute Rotation: 360°
Drive System: PTO Direct Drive
Rated RPM: 540 – 1000
PTO Height: 34″ (86 cm)
Total Weight: 1950 lbs (885 kg)
Dimensions Open (LxWxH): 108″ x 85″ x 100″ (273 cm x 215 cm x 253 cm)
Dimensions Folded (LxWxH): 85″ x 71″ x 100″ (215 cm x 180 cm x 253 cm)
Mounting System: Cat II, iMatch™ & Quick Hitch Compatible
